Pocket Air Filter
“VENT” filter are manufacturing BAG FILTER (POLYSTER MEDIA) as medium to high efficiency extended surface self-supporting pocket (bag) filters made of super fine synthetic (polyester) filter media. The progressive density multi-layered fiber arrangement offers excellent filtration performance combined with very high dust holding capacity.
VENT-AIR Poly-G model with a unique aerodynamic design is also available for air intake application like gas turbines, diesel generators and spray painting plants.
Product Details:
- Filtration Grade: Hepa Filter, Pre Filter, Ulpa Filter, Medium Filter
Advantage : -
- Filter material of newly-developed plastic fiber media
- Low initial pressure loss, flat development
- Newly-developed seam technique for better air distribution
- Conical pockets and self-supporting bags
- Molded, rigid and aerodynamically designed plastic front
- Application: Filtration for fine particle in AHU & Ventilation System
- Type: Pocket Filter
- Case: Galvanized steel / ABS
- Media: Progressive structure Polyester media
- EN 779:2002 efficiency: F5 / F9
- Eurovent efficiency: EU5 / EU9
- Average arrestance 55 to 90 %
- Final pressure drop: 250 Pa.
- Temperature: 80°C maximum in continuous service.
- Max. Relative Humidity 100% RH
