Positive Pressure Module

Positive Pressure Module
Positive Pressure Module
Send Inquiry
Product Code : 08
Product Description

Positive Pressure Module

Technical Specifications

  • Air cleanliness : ISO Class 5 / Class 100 / M 3.5 AREA
  • Air Velocities : 0.45 ± 0.05 mps (90 ± 20 FPM)
  • Air Flow : Horizontal / Vertical
  • Noise Level : Less than 65 dB
  • Vibration Level : Minimum
  • POWER SUPPLY : 230V AC,  1-Ø,  50HZ
  • MOC : GI Powder Coated / SS-304 / SS-316

Two Stage filtration (Multi Stage in Optional)

EU5 Pre- Filter (95% down to 5 micron)

EU14 - HEPA Filter - Supply / Exhaust (99.999% down to 0.3 micron)

  • Statically & Dynamically balanced Motor-blower with isolator to reduce noise level
  • ON/OFF Switches
  • DOP Port
  • DQ, IQ, OQ, PQ Documentation

Options and Accessories

A wide range of configurations to suit any containment application: -

  • Differential Pressure Gauges : 01 No. (HEPA Filter)
  • Rigid Barrier  (Flexible PVC Strip / Poly carbonate / Acrylic Sheet)
  • Velocity display with High / Low Alarms
  • Filter chocking  alarms
  • Fluorescent Lights
  • Auxiliary Powder Socket :  5/15 Amp for external equipment
