Send InquiryHooded Type HEPA Filter
Price 15000 INR/ Piece
MOQ : 1 Piece
Hooded Type HEPA Filter Specification
- Efficiency (%)
- >=99.97% @ 0.3 micron
- Temperature Range
- Up to 80C
- Cleaning Method
- Non-washable, Disposable
- Flow Rate
- 5002000 CFM (varies by model)
- Pressure
- Recommended initial resistance 250Pa
- Capacity
- Designed for continuous operation
- Connecting Type
- Flanged or gasketed
- Filtration Grade
- HEPA Filter
- Media Type
- Microfiber glass paper
- Filter Type
- HEPA Hooded Filter
- Condition
- New
- Size
- Standard
- Construction
- Wire Mesh
- Medium Filter
- Other
- Warranty
- 1
- Sealant
- Polyurethane
- Frame Material
- Galvanized steel, stainless steel optional
- Gasket Material
- Neoprene or PU foam
- Max Humidity
- 100% RH (no condensation)
- Width
- Depends on model; custom widths available
- Height
- Depends on model; custom heights available
- Size
- Standard and custom sizes available
- Length
- Depends on model; custom lengths available
- Product Type
- Hooded Terminal HEPA Filter
- Color
- Metallic/Grey
- Typical Applications
- Clean rooms, laminar air flow systems, hospitals, pharmaceutical plants
- Mounting Options
- Ceiling or wall mounting
- Service Life
- Depend on usage and environment
Hooded Type HEPA Filter Trade Information
- Minimum Order Quantity
- 1 Piece
- Supply Ability
- 20 Pieces Per Month
- Delivery Time
- 15 Days
About Hooded Type HEPA Filter
Hooded Type HEPA Filter
Product Details:
| Frame Material | G.I., Aluminium, Wooden, Stainless Steel |
"VENT" HEPA filters aremanufactured from continuous length superior quality micro glass fiber papermedia available in various efficiency grades. The filter media is moistureresistant and fire retardant. Anti-microbial treated papers are also availablefor special applications. The uniform and closed pleat filter pack grants ahigh crossing surface to hold the very fine dusts.
The standard frame construction includes fire retardant Wood Particle Board,Galvanized steel and anodized aluminum. High temperature versions areconstructed with Stainless steel frames.
Advanced Filtration Performance
Engineered with microfiber glass paper media and wire mesh construction, these HEPA hooded filters guarantee a high degree of air purity, capturing airborne contaminants with efficiency levels of at least 99.97% for particles at 0.3 micron. Reliable for demanding environments, they maintain optimal air quality in clean spaces.
Flexible Installation and Usage
The hooded terminal design allows for easy ceiling or wall mounting, adapting seamlessly to building layouts. With flanged or gasketed connection options, installation is straightforward whether used in hospitals, pharmaceutical units, or electronics manufacturing facilities.
Durable and Customizable Construction
Built to withstand up to 80C and 100% relative humidity (without condensation), the filter survives tough conditions. Customize the width, length, and height to fit your airflow needs; the sturdy galvanized steel frame or optional stainless steel adds longevity to its service life.
FAQs of Hooded Type HEPA Filter:
Q: How is the Hooded Type HEPA Filter installed in a facility?
A: The filter is designed for straightforward ceiling or wall mounting, making it compatible with various building layouts. Its flanged or gasketed connections facilitate secure installation in clean rooms and controlled environments.Q: What maintenance is required for this HEPA hooded filter?
A: This HEPA filter is non-washable and disposable. It should be replaced according to the usage intensity and specific environmental conditions, ensuring continued high-efficiency filtration.Q: When should I replace the Hooded Type HEPA Filter?
A: Replacement should occur when pressure drop exceeds recommended levels or when the filter reaches the end of its service life, which depends on usage and environment. Regular monitoring ensures optimal air quality.Q: Where can I use this filter to achieve optimal performance?
A: It is ideal for applications in clean rooms, laminar air flow systems, hospitals, and pharmaceutical industries, providing advanced particle filtration to maintain stringent air quality standards.Q: What benefits does the Hooded Type HEPA Filter offer?
A: The filter provides exceptional filtration efficiency (>=99.97% @ 0.3 micron), capacities from 500 to 2000 CFM, and adaptability to extreme humidity and temperature. It enhances safety and product quality in sensitive environments.Q: Process for customizing filter dimensions to fit specific needs?
A: Contact the supplier or manufacturer to specify preferred width, height, and length. Custom sizes are accommodated to match your air handling system, ensuring compatibility and performance.Q: Is the Hooded Type HEPA Filter suitable for continuous operation?
A: Yes, it is engineered for continuous use and maintains filtration performance in high-demand environments such as hospitals and pharmaceutical plants.
